How Many Rack Stations Does a High School Need?

By The Numbers.

To estimate your ideal rack station count, divide your largest training group by three and round up. Then divide the room’s usable width by 10' to estimate how many rack stations fit across it, accounting for depth, walkways, and the number of stations each unit provides.

Larger spaces may accommodate two or three rows of racks. Half Racks and Full Racks typically sit against walls, while Double Half Racks and Full/Half Combo Racks work well toward the center of the room or approximately 12–15' from a wall, leaving room for the lifting station and platform on the wall-facing side. These calculations give you a practical starting point for planning your facility.

Shown below at Olmsted Falls High School in Ohio, nine Alpha Double Half Racks provide 18 lifting stations and nine Lat Pull Down attachments, accommodating 54 athletes in groups of three or 72 in groups of four. Positioned in the center of the room, the racks leave space for additional machines on one side and agility ladders, plyo boxes, and warmups on the other.

Decades Of Experience

Below is our 1998 flyer for the Rack-Bench System, a revolutionary concept that others in the industry initially mocked. Our founder, Matt Purdy, combined the bench press, incline bench press, and squat rack into one versatile station, paired with a portable adjustable bench that stored upright to clear the platform for squats and other movements.

Why trust Stray Dog Strength? We were building Rack-Bench Systems before the industry knew what to call them.

As explained above, the original Rack Bench System was designed for three athletes at a time, and that remains the ideal group size today. One athlete lifts, one spots, and one rests. For heavier lifts like squats, both partners can spot, with one on each side of the bar.

Groups of four or five can also work well by incorporating supersets. In a five-person group performing back squats, one athlete lifts, one spots, and one rests before taking the next set. The other two perform complementary exercises, such as glute ham roller curls, lateral lunges, or pogos. This keeps the group moving while allowing recovery between sets of the primary lift. With 10 rack stations and 32 athletes, assign three athletes to eight stations and four to the remaining two. This uses every station and keeps groups smaller, rather than placing four athletes at eight stations and leaving two unused.

Designated Space

More Than A Barbell Holder

Our goal is to maximize rack versatility without adding clutter or too much complexity. Shown below at Bucknell University, this Alpha Double Half Rack features Alpha Arms on one side and selectorized Cable Column and Lat Pulldown attachments on the other.

The Alpha Arms pin up, the Cable Column slides up, and the lat seat and knee hold detach to clear both sides for barbell lifting. Athletes can lift with two barbells simultaneously, one on each side, or rotate through the Alpha Arms and cable attachments.

Rack Spacing

With platforms measuring 10' wide, plan for at least 6' between racks, side to side, with 8' being ideal. Our top beam connectors typically provide 6' of spacing, keeping adjacent barbells from touching and leaving room to lift. This layout provides 2' between platforms, with black ECORE Beast Plus drop zones and ECORE Rally in center section.

At 65–70 square feet per athlete, a facility serving 50 athletes at once would need approximately 3,250–3,500 square feet. Actual capacity also depends on equipment spacing, traffic flow, programming, and supervision.

Conclusion

Rack Bench Systems have become popular in sports performance facilities because they create an assembly line of strength. Identical stations let coaches program for the entire team, make individual substitutions, and keep athletes moving without bottlenecks at a few standalone machines or key attachments.
